A esfera tornada possível com painéis de parede externa
Você já ouviu o burburinho? O Sphere, conhecido como a maior estrutura esférica do mundo, é o novo local de entretenimento mais badalado de Las Vegas, inaugurado no outono de 2023. Tem capacidade para quase 18.000 pessoas e oferece tecnologia imersiva 4D que leva os shows ao vivo para o próximo nível.
Essa estrutura única exigia materiais de construção e revestimentos externos únicos que pudessem acomodar as geometrias atípicas, os cronogramas do projeto e o tráfego diário significativo de pedestres. A construção fora do local, na forma de painéis pré-fabricados de isolamento contínuo (CI) Outsulite da Dryvit, foi o principal método para agilizar a instalação da fachada e garantir o controle de qualidade das difíceis conexões do edifício.
Eficiências na Panelização de Paredes Externas
Para a base da Sphere, foi projetado um colar angular usando painéis de parede EIFS pré-fabricados com ângulos exclusivos da Dryvit. Para acelerar ainda mais o processo de painelização, um pátio de fabricação externo foi montado a apenas três quilômetros do local da construção. Lá, eles receberam as estruturas metálicas e os 142 painéis CI foram montados com isolamento e acabamentos Dryvit.
Enquanto os painéis EIFS eram pré-fabricados, as equipes trabalhavam no local para instalar o sistema de layout e clipes. O posicionamento tinha de ser exato para que as paredes com vários ângulos se encaixassem com precisão. Planos e desenhos detalhados durante a pré-construção garantiram a precisão da pré-fabricação e da instalação dos painéis.
O desafio
Para instalar os painéis CI, um guindaste de 40 toneladas colocou os painéis numerados no lugar. Os conjuntos de paredes externas trapezoidais foram posicionados em ângulos variados para fazer com que os painéis planos formassem um formato curvo. Os painéis EIFS tinham um único andar de altura e começavam com um painel de 16 pés na base e aumentavam até 37 pés para uma inclinação ascendente que se inclinava para formar o meio da esfera. Em seguida, os painéis inverteram o comprimento de 37 pés para 16 pés até o topo da esfera.
A abordagem de painelização da parede externa com a Dryvit simplificou a construção e permitiu que a Sphere tivesse uma base robusta, altamente isolada e durável o suficiente para suportar o tráfego constante de pedestres.
